Description of the technical solution:

• Access to the site: for the transfer station and collection centres, a gate was provided made of 2 wire panels with a width of 4.0 m and a height of h=2.30 m, with anti-fracking system. Electromechanical-operated barriers with a length of 4.0 m were also installed.
• Waste weighing: is done both at the entrance and at the exit of the warehouse on an above-ground road scale with a weighing capacity of up to 40 t.
• Waste reception and processing: the collected waste is transported via 16 mc garbage trucks that discharge directly into the 32 mc long courier transport containers provided with tarpaulins.

architecture:

• • Personal building: the staff building is located in the Timisoara Transfer Station and in the premises of the Deta, Faget and Jimbolia Collection Centres. The personal building is a prefabricated container with walls and ceilings made of thermal insulation panels with dimensions of 6060 x 2435 x 2600, mounted on a metal structure raised to approx. 1.10 m above the access platform.
  • Sanitary container: is located in the Timisoara Transfer Station, mounted on a metallic skeleton, placed on independent foundations 30 cm above the ground.
  • Waste discharge platform type 1: is located in the Timisoara Transfer Station and in the Deta Collection Center. It is made on reinforced concrete infrastructure and metal superstructure with 3-sided closures and galvanized backgammon coverings, mounted on metal rulers/panes.
  • Waste discharge platform type 2: is located in the premises of the Deta and Jimbolia Collection Centers. It is made on reinforced concrete infrastructure and metal superstructure with 3-sided closures and galvanized backgammon coverings, mounted on metal rulers/panes.
  • Enclosure and gate: for the enclosure and gate of the premises of the Timisoara Transfer Station and the premises of the Collection Centers Ofta, Faget and Jimbolia were provided fences made of metal panels with wire mesh and metal access gates. Metal panels are protected against corrosion with primer, over which oil paint is performed in two layers.

Civil constructionand and building structures:

Object 1 – Timisoara transfer station:

• Rainwater retention basin;
• Oil separator (foundation);
• Wall of support;
• Foundations container personal building and sanitary container;
• Foundation scales.

Object 2 – Deta Collection Center:

• Hydrocarbon separator (foundation);
• Pool of resonant puvial waters;
• Wall support from the waste discharge platform. Infrastructure and superstructure silos;
• Personal building container foundation;
• Foundation scales.

Object 3 – Faget Collection Center:

• Hydrocarbon separator (foundation);
• Wall support from the waste discharge platform. Infrastructure+superstructure silos;
• Personal building container foundation;
• Foundation scales.

Object 4 – Jimbolia Collection Center:

• Rainwater retention basin;
• Hydrocarbon separator (foundation);
• Wall support from the waste discharge platform. Infrastructure+superstructure silos;
• Personal building container foundation;
• Foundation scale;
• Container foundations.
